The sizing of your hydraulic chlorination system is essential
As each drinking water network is different, a detailed sizing study is recommended to guarantee the correct functioning of the system according to your field conditions.
We calculate the necessary hydraulic elements, we produce tailor-made plans and integrate them into your Gravikit ® . installation is thus facilitated and you save time
Nos références
Les Gravikit offrent une solution écologique pour assurer la conformité bactériologique de l'eau potable, même dans les environnements les plus reculés. Conçus sans besoin d'électricité, ni panneaux solaires, ni batteries, ces kits de désinfection sont parfaitement adaptés aux zones rurales et difficiles d'accès.
Grâce à leur installation simple et manuelle, et leur capacité à s'ajuster automatiquement au débit d'eau, ils garantissent un dosage précis, même dans des conditions de pression variables. Robustes et fiables, les Gravikit restent performants face aux défis spécifiques des environnements complexes. Ils sont ainsi votre allié idéal pour les installations rurales et urbaines !
Voici les 8 raisons d'installer un GRAVIKIT® sur votre réseau
# 1-You save money; They are autonomous in Energy
and do not require solar panels or batteries
# 2-You respect the regulations because they use the only ACS hydraulic proportioners on the market
# 3-You dose according to consumption; They dose proportionally to the flow rate without a pulse generator!
# 4-You install and maintain them yourself; They are installed and adjusted manually
# 5 - You master the dosage; their accuracy is not influenced by variations in pressure or flow
# 6 They are self-priming and not sensitive to outgassing
# 7 They contain a built-in flowmeter
# 8 They are compatible with acidic or alkaline reagents
Hydromotor operation is based on the imbalance of forces inside a chamber filled with water. The water to be treated enters the metering device and leaves it with a percentage of metered product.
A so-called "motor" piston is driven by the movement of water passing through the metering device.
The motor in turn drives a second piston called a “metering piston” which sucks, like a syringe, an adjustable volume of product to be injected. The dosage is proportional to the incoming flow, and manually adjustable by simple action on an adjustment wheel.
The "clicks" caused by the movement of the motor guarantee the correct functioning of the system. simple, reliable, precise, dare to dose without electricity!
Adjusting the processing rate becomes child's play!
Thanks to the graduated dosing screw, you control in real time what you dose!
You don't have to know a stroke length or pulse rate.
The dosage is proportional, visual and controlled!
Flow range
from 10L / h to 30m3 / h
Dosage
from 0.125% to 2%
Connect, adjust, dose!
The Dosatron pump is connected in series on your water network for high accuracy, or bypass for higher flow installations.
You can install the pump in the GRAVIKIT ® formula:
-In a valve chamber or manhole isolated from the gel upstream of the tank (which we prefer for good disinfection of the stored volume.)
The pump can be installed on all materials: Steel, INOX, HDPE, PVC, Cast iron by integrating the necessary accessories included in the GRAVIKIT ® after study provided in GRAVIKIT ® .
Prepare your solution and adjust the set screw according to the submitted calculation note to meet your treat rate.
